Brand | IDEALPLUSING |
Model | IPS-ATDYN6025 |
AC Input | Single phase 220VAC±15% optinal |
Input Voltage Range | 220VAC±15% optinal |
Input frequency | 50Hz/60Hz |
Output voltage | 0~60VDC |
Output current | 25A |
Output Power | 1500W |
Voltage Stabilization | ≤0.3%+10mV |
Load Stabilization | ≤0.5%+30mV |
Ripples and Noises | ≤0.5%+10mVrms |
Voltage Display Accuracy | 3-digit Accuracy: ±1%+1 word |
Display Format | 0.000V-9.999V; 0.00V-99.99V; 0.0V-999.9V |
Current Display Accuracy | NO current display |
Output Over Voltage Protection | Built-in O.V.P. protection, protection limited value is rated +5% |
Output Over Load Protection | Overload, current limit, constant current output |
Over Temperature Protection | Built-in O.T.P. protection, Protection value 85℃±5% heat sink temperature |
Voltage Setting | 10-turn precision potentiometer |
Current Setting | NO current display potentiometer |
Output Polarity | Output Positive（+) negative（- ) Can be grounded at will |
Heat Dissipation Way | Forced fan cooling |
Work Conditions | Indoor use design，Temperature：0℃~40℃； Humidity： 10%~85%RH |
Storage Conditions | Temperature：-20℃~70℃；Humidity： 10%~90%RH |
Power Supply Dimension | 265*145*65MM |
Packaging Carton Dimension | 300*180*150(MM) |
Net Weight | 5KG |
Gross Weight | 6KG |
