Ⅰ.TECHINCAL PARAMETER
Brand | IDEALPLUSING |
Model | IPS-IY-320-12 |
Product name | DC-DC Converter |
Type of cooling | Nature Cooling |
Power | 1000W |
Output Voltage | 14V |
Output Voltage Range | 8-15V |
Output Current | 72A |
DC Input voltage | 320V |
DC Input voltage Range | 206-454V |
DC Input Current | 3.5A |
Max Input Current | 6A |
NW; GW | NW: 2.7KG; GW: 3.7KG |
Dimension | 45.5*24.5*18(MM) |
Ⅱ .MODEL LIST
MODEL | Output Voltage | Output Current |
IPS-IY-72-12 | 14V | 72A |
IPS-IY-108-12 | 14V | 72A |
IPS-IY-144-12 | 14V | 72A |
IPS-IY-320-12 | 14V | 72A |
IPS-JH-72-12 | 14V | 110A |
IPS-JH-108-12 | 14V | 110A |
IPS-JH-144-12 | 14V | 110A |
IPS-JH-320-12 | 14V | 110A |
IPS-TCD-320-14 | 14V | 143A |
