IPS-SP48-8.3 Hot sale led smps 12v 24v 36v 48v 400w dc output mode switching supply led strip power
MODEL:IPS-SP48-8.3 48v switching power supply SPECIFICATION: ① AC input: Single-phase 110/220V±15% 50/60hz ② DC output: 0~48VDC, 8.3A ③ Power: 400W ④ Dimension: 215*115*50MM ⑤Package size: 23(L)*13(W)*7H)CM ⑥NW: 0.9KG, GW: 1.4KG

I.FEATURES

1

Hot sale led smps 12v 24v 36v 48v 400w dc output mode switching supply led strip power

2

Adjustable with Compact size, light weight

3

Wide range AC Input , AC input 110V/220Vac input selected by switch

4

100% full load burn-in test

5

Protection: Short circuit / Over load / Over voltage

6

Fixed switching frequency at 25KHz

7

1 year warranty

8

High efficiency, reliability quality, competitive cost

9

0-5Vdc / 0-10Vdc External control output (Optional)

10

Extra adjustable potentiometer (Optional)

11

Output voltage adjustable, output current be fix



II. COMMON SPECIFICATION

Adjustable range for dc voltage

The output voltage is 100% adjustable through the potentiometer

AC input voltage range

AC 95-125V 60Hz | AC174-264VAC 50Hz Manual switch

Input current

115V/4.23A / 230V/2.12A

leakage current

≤1.5mA 230V AC

Overload protection

Load more than 110%~120% switch to constant current mode

Over-voltage protection

≥15% of output voltage

Setup rise hold time

200ms  100ms  20ms

Vibration

10-50Hz, 2G 10 minutes/cycle X, Y, Z axis each 60 minutes

Withstand voltage

Input to shell 1500V/3mA AC | Input to output 1500V/3mA AC | Input to output 500V/3mA AC

working temperature

-10℃-65℃, 20%-90%RH

Storage temperature

-10℃--65℃, 20%--95%RH

Net weight

0.9KG

Dimension

215L*115W*50H (MM)

OTHERS

Output voltage tolerance

1%

Wave and noise

150mV P-P

Efficiency

91%

III. MODEL INFOMRATION

MODEL

OUTPUT VOLTAGE

OUTPUT CURRENT

OUTPUT POWER

IPS-SP12-33.3

0-12VDC

33.3A

400W

IPS-SP24-16.7

0-24VDC

16.7A

400W

IPS-SP36-11.1

0-36VDC

11.1A

400W

IPS-SP48-8.3

0-48VDC

8.3A

400W

IPS-SP60-6.7

0-60VDC

6.7A

400W

IPS-SP90-4.4

0-90VDC

4.4A

400W

IPS-SP110-3.6

0-110VDC

3.6A

400W

IPS-SP150-2.7

0-150VDC

2.7A

400W

IPS-SP200-2

0-200VDC

2A

400W

IPS-SP220-1.82

0-220VDC

1.82A

400W

IPS-SP240-1.68

0-240VDC

1.68A

400W

IPS-SP260-1.54

0-260VDC

1.54A

400W

IPS-SP280-1.43

0-280VDC

1.43A

400W

IPS-SP300-1.33

0-300VDC

1.33A

400W

IPS-SP330-1.21

0-330VDC

1.21A

400W
