IPS-ATDH12600 Factory Test Use 600A / 6V 12V 24V 36V water-cooled plating rectifier PCB circuit board plating power supply equipment
Model :IPS-ATDH12600 12VDC 600A AC DC Power Supply ① AC INPUT: 3 phases 380VAC ±15% 50/60HZ ② DC OUTPUT: 0~12VDC, 0~1000A ③ Max Power: 7.2KW ④ Size of machine : L650*W380*H280(MM) ⑤ NW: 45KG, GW: 55KG ⑥ Protection:Lack phase, Over-heating,Over-voltage,Over-current,Short-circuit ⑦ Communiction: RS485*1 Wechat ID:idealplus_power Wechat Number/Whatsapp ID:+86 159 8913 2799 Email:power@idealplusing.com Office telephone number:+86-20-89282095 We specialize in customizing DC power supply to meet your specific requirements. With customized input and output voltage and current, our offerings range from 0V to 2000KV DC and 0A to 2000A. We provide AC-DC solutions for the motor category or electrical appliances testing or Lab testing, electrochemistry, electrolysis, electroplating, and anodizing. Please visit our website and submit any inquiries to explore our capabilities further. Our dedicated team endeavors to respond within one hour. Thank you for considering our services.


I. INTRODUCTION

    The adjustable power supply adopts high frequency switching power technology. it is controlled by high performance microcomputer. The voltage and current can be adjusted independently.

    The adjustable power supply widely used in industrial control and electronic products aging and testing. It is suitable for all kinds Resistance load, capacitive load, inductive load

II. CUSTOMIZED RANGE

1 Phase: AC220V/120V±15%,50Hz/60Hz

3 Phase: AC380V±15%,50Hz/60Hz

3 Phase: AC450V±15%,50Hz/60Hz

1~10000V,Stabilizer voltage value. 1% to 100% adjustable

1~5000A,Constant current value. 1% to 100% adjustable

Adjustable mode: Keystroke type / Knob type / Touch screen optional

III. TECHNICAL PARAMETER

Brand

IPS-ATDH12600

AC INPUT

3 phases 380VAC±15% 50/60HZ

DC OUTPUT VOLTAGE

0~12VDC

OUTPUT CURRENT

0~600A

Output characteristic

Constant voltage and constant current switchable

Output power

7.2KW

Voltage output accuracy

0.5%FS

Current output accuracy

0.5%FS

Source effect

≤0.2%FS

Load effect

≤0.2%FS

Voltage Display resolution

0.1V

Current Display resolution

0.1A

ripple factor(Vrms)

≤2% FS

Operating characteristics

Support (24*7) long time

Work Efficiency

>90%

Power factor

>93%

Adjustment accuracy

<0.1%

Protection mode

Lack phase

Over-heating

Over-voltage

Over-current

Short-circuit

Output indicator

LED digital voltage and current display

Cooling fan

Force cooling

Ambient temperature

-10~+40 degree

Insulation strength

Input-output; Input-chassis; AC200V, 10mA, 1min

Insulation resistance

Input-output; Input-chassis; Output-chassis: > 20m

Insulation grade

B

Waterproof Level

IP20

Protect Level

IP20(Instructions for ordering protective levels for equipment in special environments)

Dimension

 L650-W380-H280 (MM)

NW

45KG

Application

Testing aging of electronic and electrical products, testing of new energy vehicles, scientific research institutions or school laboratories and experiments, etc.

Special Function Customization

Optinal, and price will be change if add these

Time control function, ampere hour meter function, intelligent temperature control function. Intelligent computer touch screen display operation interface. RS-485,PLC or RS232 communication port , LC Filtering function
