The EMI filter circuit in the PC power supply can not only filter out the high-frequency noise of the mains and stabilize the power supply operation, but also protect the power supply through MOV and NTC components, reduce its own external electromagnetic interference and suppress pollution to the power grid. When purchasing, you need to pay attention to its integrity to ensure that the power supply is stable and reliable and reduce interference.

PC power supply is a device that provides power for personal computers. It is an important part of personal computers. The function ofPC power supplyis to convert AC power into DC power and provide stable and reliable power for various components inside the computer. The working principle of PC power supply involves multiple fields such as power electronics technology and electromagnetism.



The basic working principle of PC power supply is to convert AC power into DC power. It consists of power transformer, rectifier, filter, voltage regulator and other parts. The power transformer reduces the voltage of AC power to low-voltage AC power, the rectifier converts low-voltage AC power into DC power, the filter removes the AC ripple in DC power, and the voltage regulator stabilizes the DC power at the voltage level required by the computer.



EMI filter circuit is essentially a low-pass filter. Its main task is to filter out high-frequency noise in the input mains power. These noises may come from other devices in the power grid or may be generated by the power supply itself. Through the filtering of the EMI filter circuit, only pure 50Hz AC power can enter the subsequent rectifier and voltage regulator circuit, thereby ensuring the stable operation of the power supply.



Protection of PC power supply

In addition to the basic filtering function, the EMI filter circuit also has the function of protecting the PC power supply. The MOV (metal oxide varistor) and NTC (thermistor) in the circuit are key protection components. MOV can suppress the sudden voltage in the mains input to prevent excessive voltage from damaging the power supply; while NTC can limit the current impact when the power supply starts, protecting the power supply from damage caused by the current impact. These protection measures together constitute the first line of defense for the PC power supply, ensuring that it can still operate stably in harsh electrical environments.



Reduce external electromagnetic interference

When the PC power supply is working normally, it will also emit electromagnetic waves to the outside, which may interfere with the normal operation of other PC hardware. The existence of the EMI filter circuit can effectively reduce the EMI generated by the power supply itself and reduce the electromagnetic interference radiated to the outside. This is of great significance to ensure the stability and reliability of the entire PC system.



Impact and protection on the power grid

EMI is not only limited to a single device, but also propagates along the power line to the power grid, affecting the normal operation of other electronic equipment in the power grid. The EMI filter circuit can also suppress the pollution of the PC power supply to the power grid, ensuring that it will not have adverse effects on other devices in the power grid. This function is of great significance for maintaining the stable operation of the power grid and improving the quality of power.



When purchasing a PC power supply, the integrity of the EMI filter circuit is a factor that cannot be ignored. An excellent PC power supply should have a complete EMI filter circuit to ensure that it can work stably and will not have adverse effects on other hardware or the power grid. Therefore, when purchasing, consumers should pay attention to the description of the EMI filter circuit in the product specification and choose products that have been strictly tested and verified.
