As the energy core of industrial equipment, industrial AC/DC DC power supplies are often deployed in complex scenarios such as outdoor base stations, chemical production lines, water conservancy facilities with high humidity, dust, or even direct liquid contact. The quality of waterproof design directly determines their operational stability, service life, and even the operational safety of the entire industrial system. Unlike the simple waterproof treatment of consumer-grade power supplies, the waterproof design of industrial-grade products is not a single sealing process, but needs to strictly follow industry universal standards and carry out systematic design combined with the environmental characteristics of the application scenario. The implementation of each standard corresponds to the core requirements of the power supply's protection capability and is also an important guarantee for the reliability of industrial products.
1. IP Protection Rating Standard: The Basic Framework of Waterproof Design
The IP protection rating is the core standard for the waterproof design of industrial AC/DC DC power supplies, formulated by the International Electrotechnical Commission (IEC) 60529, and is also a globally accepted basic protection specification. The standard consists of two digits, the first representing dustproof capability and the second representing waterproof rating. The core of the waterproof design of industrial power supplies revolves around the second digit, with different values corresponding to different waterproof capability requirements, and professional spray and immersion tests are required for verification.
For industrial AC/DC power supplies used in light-load outdoor applications, they usually need to meet the IP65 waterproof rating, which requires the power supply housing to resist low-pressure water spraying from any direction without liquid penetrating into the internal circuit; for power supplies used in underwater operations, water conservancy projects and other scenarios, the IP68 rating is required. This rating requires the power supply to be completely immersed in water at a specified depth and time while keeping the interior dry. Its sealing design must take into account the liquid penetration risk caused by pressure difference. The IP protection design of industrial power supplies is not simply to upgrade the rating, but to balance with the heat dissipation requirements of the power supply to avoid excessive sealing leading to the inability of heat dissipation from power devices inside the power supply. Therefore, while following the IP standard, a waterproof heat dissipation structure must be matched to achieve both protection and heat dissipation standards.
2. IEC 61010 Standard: Synergistic Requirements for Electrical Safety and Waterproofing
IEC 61010 "Safety Requirements for Electrical Equipment for Measurement, Control and Laboratory Use" is a general safety standard for industrial electrical equipment. Its requirements for the waterproof design of AC/DC DC power supplies are not specified separately, but combine waterproofing with electrical insulation and electric shock protection to form synergistic requirements. The standard clearly states that the waterproof sealing structure of the power supply shall not affect the insulation performance. When the waterproof components are aged or damaged, the insulation resistance and withstand voltage value of the power supply still need to meet the rated requirements to prevent insulation failure caused by liquid penetration and trigger safety accidents such as short circuit and electric leakage.
In actual design, complying with the IEC 61010 standard requires special waterproof treatment for the weak parts of the power supply such as interfaces and wiring terminals, such as using waterproof aviation plugs instead of ordinary interfaces, adding waterproof rubber rings at the terminals and performing potting treatment. At the same time, the material of the waterproof structure is required to have anti-aging and anti-corrosion characteristics to adapt to the temperature and humidity changes in industrial scenarios. The core of this standard is to make the waterproof design a guarantee for electrical safety, rather than an independent protection link, ensuring that the power supply is not damaged by liquid in a humid environment and can also guarantee the electrical safety of equipment and operators.
3. UL 508 Standard: Special Waterproof Requirements for Industrial Control Scenarios
UL 508 "Standard for Industrial Control Equipment" is a dedicated standard for industrial control equipment in North America, applicable to AC/DC DC power supplies used in North American industrial production lines. Its requirements for waterproof design are more in line with the actual needs of industrial control scenarios. The standard puts forward detailed waterproof requirements for the installation method, housing protection and wiring method of the power supply. For example, the housing splice of the power supply shall adopt a continuous waterproof gasket, and the screw fastening part shall be treated with anti-loosening and waterproof measures to avoid the loosening of the sealing structure caused by equipment vibration, which may lead to liquid penetration.
In addition, the UL 508 standard also requires the waterproof design of the power supply to pass the high and low temperature cycle test, simulating the impact of temperature changes in industrial scenarios on the waterproof structure, and verifying whether the protection performance of the sealing material remains stable after thermal expansion and contraction. For AC/DC power supplies used in explosive industrial scenarios, the standard also combines waterproof design with explosion-proof requirements to prevent internal electric arcs caused by liquid penetration, which may trigger explosion risks. This is also an important difference between the waterproof design of industrial power supplies and ordinary power supplies.
4. GB/T 14048 Series Standards: Adaptation Specifications for Domestic Industrial Scenarios
In the domestic industrial field, the waterproof design of AC/DC DC power supplies also needs to follow the national standard GB/T 14048 series, which is equivalent to adopting the relevant IEC standards and making detailed supplements combined with the environmental characteristics of domestic industrial scenarios. For example, in coastal industrial scenarios with high humidity and high salt spray, the standard requires the waterproof structure of the power supply to have salt spray corrosion resistance at the same time. The sealing material shall adopt salt spray resistant silicone rubber or fluororubber, and the housing surface shall be treated with anti-corrosion coating to prevent salt spray from penetrating into the interior through waterproof gaps and causing corrosion of circuit boards and devices.
The GB/T 14048 series standards also clearly stipulate the waterproof test method for power supplies, requiring the waterproof test of industrial power supplies to be carried out under the rated working state instead of no-load test, which is more in line with the actual use scenario. It is ensured that the waterproof structure of the power supply can still function when it is working normally and generating heat, avoiding the increase of sealing gap caused by the change of working temperature and affecting the waterproof effect.
The waterproof design of industrial AC/DC DC power supplies is essentially the comprehensive implementation and scenario-based adaptation of various standards, not the execution of a single standard. From the basic IP protection rating to electrical safety, regional special standards and domestic adaptation specifications, each standard defines the core requirements of waterproof design from different dimensions. In actual R & D and production, it is necessary to integrate the requirements of various standards into all links such as housing structure, sealing material, interface design and heat dissipation scheme in combination with the application scenario and use area of the power supply, so that the industrial AC/DC power supply can maintain stable operation in complex humid environments and become a reliable energy support for the industrial system.
