Electroplating power supply is actually a kind of power converter, which can convert the AC voltage of the power grid into low DC or pulse voltage, so as to be used for electroplating. In the process of continuous development of science and technology, the content involved in the electroplating industry has been increasing, and the scope of use has been expanding.

People's demand for plating has also been increasing, requiring the electroplating power supply to have a higher operating frequency. Therefore, the research and development of new electroplating power supplies has attracted people's attention.

Modern power converters are gradually developing in the direction of high frequency, which has brought new opportunities for the development of electroplating power supplies. Effectively improving the switching frequency of switching devices has many benefits for power converters, such as increasing the density, volume and response capability of power converters.

The conversion technology of traditional electroplating power supplies limits the effective improvement of the working efficiency of power converters and cannot meet the trend of modern high frequency. This article mainly analyzes the design and use of high-power switching electroplating power supplies.

Research on the hardware design of high-power high-frequency switching electroplating power supply

Overall design plan

According to the design requirements, in order to effectively realize the high-power current output of the electroplating power supply, the power supply designed in this paper uses multiple sub-modules in parallel, in which the input end of the circuit is connected to the 380V three-phase AC power, and the current of the CPU and other control circuits is provided through rectification and filtering.

Part of it is transmitted to the sub-module power supply through the contactor and the main fuse, and rectified by the three-phase rectifier bridge into a 540V DC voltage, which is provided to the full-bridge power conversion module through filtering, and then the DC voltage is filtered through rectification and filtering.

The CPU control unit and LCD and keyboard are connected to each other to realize the adjustment, display, communication and protection of voltage and current output.

The full-bridge phase-shifted zero voltage switch is used as the main circuit of the high-frequency inverter circuit, and the soft switching technology is used to realize high-power and low-loss high-frequency inverter.

The high-frequency switch tube uses a high-power module, which can effectively improve the reliability of the power supply during use.

The main purpose of the control unit outputting the control signal is to achieve a rapid response of the main circuit output, so as to obtain dynamic and static output characteristics, and to achieve various input voltage fluctuations, and to achieve protection response for faults caused by various factors.

Design of the drive circuit

The IGBT drive circuit is used, which is a voltage drive element, a fully controlled device, with a large input impedance, and is more sensitive to gate charge, with a threshold voltage of 3V-6V, so it has higher requirements for the drive circuit.

There are many IGBI drive circuits, and photoelectric coupling or transformer coupling is used in high-power occasions. The photoelectric coupling driver is active on both sides, and the pulse width provided by it will not be limited. It can detect the IGBT on-state collector voltage, and can also achieve short-circuit and overcurrent protection in various situations, and can also output overcurrent signals to the outside.

However, this method requires more working power supplies to be implemented, which increases the complexity of the circuit. On the contrary, the transformer coupling driver does not need to set the working power supply, and has a faster working speed and higher input and output withstand voltage. Then this article uses transformer coupling drive to obtain a continuous reverse gate voltage during the shutdown process for the drive short circuit.

On the basis of using transformer coupling drive, in order to enable the switch tube of the driving circuit to conduct quickly and the tube section, a high-speed driver chip is used in the design process, so as to provide a larger peak drive current.

High-frequency transformer

The high-frequency transformer is a magnetic component for energy transmission and electrical isolation. It is an important component in the switching power supply.

Its performance directly affects the efficiency of the transformer itself and determines the performance of the power supply system.

The transformer design process includes the selection of three devices, namely the primary and secondary turns, the primary and secondary turns ratio, and the magnetic core. In the process of selecting the magnetic core, the main selection is the geometric shape and material.

The main materials include ferrite and permalloy. Ferrite has ferromagnetism and high resistance, so it can be easily used in high-frequency transformers.

Power supply experiment

Through theoretical analysis, the design of the electroplating power supply was realized, and a high-power high-frequency switching electroplating power supply with water cooling was successfully developed. Its operating frequency and power are 20kHz and 18kV respectively.

The main circuit experimental device in this article is a box structure with a small volume and light weight.

The power components and the primary and secondary windings of the high-frequency transformer are all cooled by water. The three promotion tubes on the upper right are cooling water pipes, and the main circuit conductive path steel pipe is hollow.

Below the experimental device are the high-frequency transformer, filter circuit and output rectifier circuit. The working principle of electroplating is to pass the adsorbed oppositely charged ions of the power supply electrode, because the ion movement becomes current. However, due to the limitation of conditions, in order to realize the simulation of electroplating at the production site, sodium chloride solution is used as the electrolyte during the experiment, and the positive and negative electrodes of the electroplating power supply output and the aluminum plate are connected to each other and placed in the sodium chloride solution.

Shorten the distance between the plates, that is, to increase the load and output current. Because there is current, sodium chloride starts to react. The positive pole of the power supply turns black due to the adsorption of negative ions, and the negative pole of the power supply turns white.

The larger the current, the more intense the reaction. The simulation system of the on-site fault can respond correctly, stop the pulse, protect the module, and switch between constant voltage and constant current. The output voltage can be adjusted.

This device was installed in the electroplating production line of a certain material company. After one year of operation, it can be seen that the system designed in this paper works stably, the system is good, and the energy consumption is low, so it can continue to be used.

Application trend of electroplating power supply

High frequency and high efficiency

The switching power supply used by high-power high-frequency switches can replace the traditional rectifier power supply, which can effectively reduce losses and increase power density.

Modern electroplating switching power supplies are mainly used in small and medium powers below 1500A. Therefore, the use of advanced power electronic devices and technologies can innovate the output power limitations of modern power devices and magnetic materials.

The power output capacity of the switch tube can be fully utilized through the series and parallel connection of transformers, thereby effectively improving the output efficiency of the single machine power.

The use of multi-unit building block parallel technology can effectively improve the power supply output capacity. Soft switching technology can effectively reduce the switching loss of the device, thereby effectively increasing the switching frequency and optimizing the working environment of the device.

This technology can reduce the power switch loss in the high-frequency state, improve the overall efficiency of the power supply, and effectively increase the working frequency of the power supply.

Intelligence

The electroplating process is required to eliminate the influence of human factors and reduce the process energy loss, which puts forward a high demand for power supply intelligence. From the perspective of energy saving and improving process quality, in addition to the power supply device loss, the process energy consumption also occupies a large part of the content in electroplating.

The main factors affecting the process energy consumption are current efficiency and tank pressure. By detecting parameters such as electrolyte temperature and concentration, the power supply current and voltage output are reasonably adjusted to achieve the purpose of energy saving and efficiency improvement and process quality improvement.

From the control aspect, the electroplating process converts the energy of electroplating into a nonlinear time-varying system, and it is impossible to create a standard model to achieve control.

Intelligent control can be independent of people, and can be controlled accordingly through people's operating knowledge and experience, thereby effectively improving the process quality and performance of electroplating power supply.

Therefore, in the continuous development of electroplating technology, it is necessary to develop intelligent power supply equipment that meets different process requirements, so as to meet the development needs of new technologies in modern society.
