Overview of adjustable DC regulated power supply:
Adjustable DC regulated power supply is a device that can provide stable DC voltage and is widely used in electronic laboratories, production and testing equipment. It can adjust the output voltage according to the load requirements to ensure that electronic equipment obtains accurate voltage and current under different working conditions.
Application scenarios:
Adjustable DC regulated power supply is widely used in many fields such as laboratories, industrial production, automobile maintenance, power systems and home appliance maintenance. It can not only provide stable power supply for various electronic equipment, but also play an important role in the debugging and troubleshooting of electronic equipment.
Function of adjustable DC regulated power supply:
SW-A/SW-S series products are digital display programmable switching DC regulated power supply, which can display voltage, current and power at the same time. Its output voltage and output current are pre-adjusted by the encoder knob and can be continuously adjusted between 0 and the nominal value. The stability and ripple factor of the power supply are very good, and it has a variety of protection circuits such as short circuit protection, overvoltage protection, overcurrent protection, overtemperature protection, etc. The product has beautiful design, convenient operation, and can work at full load for a long time. This machine is equipped with a USB fast charging interface.
Recommended models:
MODEL：IPS-ATDM1560 Adjustable DC Regulated Power Supply
SPECIFICATION：
① AC input: 220VAC±10%,50Hz or 110VAC
② DC output: 15VDC, 60A
③ Power: 900W
④ Dimension:330*250*155MM
⑤ NW: 5KG
FEATURE
●LED digital display provides a simple and intuitive display of the voltage, current, power, and equivalent resistance of the power output
●Automatic switching between stable voltage and stable current
●Equipped with output control switch for more flexible control
●Overvoltage, over-current, over-power, over temperature, short circuit protection
●Convenient and fast operating interface
●Temperature controlled fan speed makes the instrument have low noise and longer fan life
●Pre designed voltage and current values for easy operation when the output is turned off
MODEL：IPS-ATDM30200 High Precision Desktop Power Supply
SPECIFICATION：
①AC input: 220VAC±10%,50Hz or 110VAC
② DC output: 30VDC, 200A
③ Power: 6000W
④ Dimension: 330*250*155MM
⑤ NW: 5KG
FEATURE
●LED digital display, simple and intuitive display of power output voltage, current, power, and time
Stable voltage and stable current automatic switching, one key output on/off switch, more flexible output control
●Five powerful protection functions including overvoltage, overcurrent, over power, over temperature, and short circuit protection
●6 sets of quick parameter callback and storage functions
●Programmable sequence output with hardware List
●Standard RS-485 serial port, supports Modbus programming instructi on set
●Standard SENSE compensation interface
●Switchable options for output timing shutdown and output timing function
●Voltage and current values can be pre designed for easy operation when the output is turned off
●Temperature controlled fan, energy-saving and power-saving
●One click keyboard lock to prevent accidental operation
Conclusion:
In summary, the adjustable DC regulated power supply is an essential tool for electronic engineers and electronics enthusiasts, and it plays a key role in various fields and applications. With the development of technology, the performance and functions of the adjustable DC regulated power supply will continue to improve and be applied in more fields. During maintenance and troubleshooting, safety regulations should be strictly followed to ensure the safety of the power supply and personnel.
