Brand | IDEALPLUSING |
Type | Isolate |
Model | IPS-DTD20-120S121.5 |
INPUT | |
Rate Volts | 12VDC |
Volts range | 20-120VDC |
OUTPUT | |
Efficiency | 92% |
Output volts | 12VDC |
Output current | 1.5A |
Rated Power | 18W |
OTHERS | |
Voltage regulation | < 1% |
Load regulation | < 2% |
Ripple | < 50mV |
No-load current | < 20mA |
Working Temp | -40°c ~ +80°c |
Waterproof rating | IP65 |
Machine size | / |
NW | / |
Cooling way | Free air convection |
Certifications | CE, RoHS |
Customize | Support |
Sample order | Support |
OEM & ODM | Support |
Package | White & colorful package optional |
