INTRODUCE
This series is a high-quality, high-stability economical DC regulated power supply, LED four-digit voltage and current display, with over-voltage protection, over-current protection, OVP/OCP can be set as required. Extremely high stability, extremely strong reliability. At the same time, this series of power supplies can be equipped with programming interface to achieve remote control or automatic control.
FEATURE
●300W constant power wide range, one at most units.
●ON/OFF switch.
●The power on output turns the external SETUP function on or off.
●The digital control of the coded switch is convenient, stable and durable.
●Three sets of preset parameter storage functions.
●The OVP and OCP gate values can be set directly.
●Programmable settings, support MODBUS communication protocol.
SPECIFICATION
Brand | IDEALPLUSING | ||||
Product name | Mini wide range power Supply | ||||
Model | IPS-ATDM4020HP | IPS-ATDM8010HP | IPS-ATDM1605HP | ||
Voltage(VDC) | 40VDC | 80VDC | 160VDC | ||
Current(AMPS) | 20A | 10A | 5A | ||
Output power(WATT) | 300W | 300W | 300W | ||
Voltage | |||||
Set resolution | ＜100V :10mV ; ≥100V : 0.1V | ||||
Setting accuracy | ≤0.1%+5 digits | ||||
Readback resolution | ＜100V :10mV ; ≥100V : 0.1V | ||||
Readback accuracy | ≤0.1%+5 digits | ||||
Ripple | ≤12mVrms | ≤12mVrms | ≤12mVrms | ||
Current | |||||
Set resolution | ＜10A : 1mA ; ≥10A: 10mA | ||||
Setting accuracy | ≤0.2%+10 digits | ||||
Readback resolution | ＜10A : 1mA ; ≥10A: 10mA | ||||
Readback accuracy | ≤0.2%+10 digits | ||||
Ripple | ≤18mArms | ≤18mArms | ≤26mArms | ||
Load regulation | ≤0.2%Vmax+5mV | ||||
Power regulation | ≤0.2%Vmax+5mV | ||||
OVP | 0-Vmax±0.2% FS | ||||
Maximum voltage | Vmax±0.2% | ||||
OCP | 0-Cmax±0.2% FS | ||||
Maximum current | Cmax±0.2% | ||||
Working conditions | Temperature: 0~40°C Relative humidity: ≤80%RH | ||||
Storage conditions | Temperature: -20~60°C Relative humidity: ≤80%RH | ||||
Cooling method | Air cooling | ||||
Weight | ≤2.2KG | ||||
Size(No packaging) | 80×150×230mm | ||||
MODEL LIST
Model | Output Peak Voltage(VDC) | Output Peak Current(AMPS) | Output Peak Power(WATT) | Size (MM) |
IPS-ATDM4020HP | 40VDC | 20A | 300W | 80×150×230MM |
IPS-ATDM8010HP | 80VDC | 10A | 300W | 80×150×230MM |
IPS-ATDM1605HP | 160VDC | 5A | 300W | 80×150×230MM |
