IPS-DTD12S2440 10V 14V 15V to 24V 8A 20A 40A 960W Boost DC to DC Converter Power Supplies
IPS-DTD12S2440 10V 14V 15V to 24V 8A 20A 40A 960W Boost DC to DC Converter Power Supplies
Model : IPS-DTD12S2440
Specification :
① Input: 12VDC（10-15VDC）
② Output: 24VDC 40A
③ Max power: 960W
④ Material of shell: Aluminum
⑤ Size: 180*127*63MM
⑥ Input & Output cable: 13~15CM
⑦ NW: 1800G, GW:2000G
⑧ Design: Non isolate and waterproof IP65
We specialize in customizing DC-DC converters to meet your specific requirements. With customized input and output voltage and current, our offerings range from 1V to 10000VDC and 1A to 1000A.
We provide both isolated and non-isolated converter design options. Please visit our website and submit any inquiries to explore our capabilities further.
Datasheet： Download
Brand | IDEALPLUSING |
Name | IPS-DTD12S2440 10V 14V 15V to 24V 8A 20A 40A 960W Boost DC to DC Converter Power Supplies |
Type | Non-Isolate |
Model (IPS-***) | IPS-DTD12S2440 |
INPUT | |
Rate Volts | 12VDC |
Volts range | 10-15VDC |
OUTPUT | |
Efficiency | 92% |
Output volts | 24VDC |
Output current | 40A |
Rated Power | 960W |
OTHERS | |
Voltage regulation | < 1% |
Load regulation | < 2% |
Ripple | < 50mV |
No-load current | < 20mA |
Working Temp | -40°c ~ +80°c |
Waterproof rating | IP65 |
Machine size | 180*127*63(MM) |
NW | 1800G |
Cooling way | Free air convection |
Certifications | CE, RoHS |
Customize | Support |
Sample order | Support |
OEM & ODM | Support |
Package | White & colorful package optional |
