Brand | IDEALPLUSING/OEM | ||
Model No | IPS-BC12200 | ||
Input Voltage | 200~240VAC 50HZ/60HZ or single phase 110VAC 50HZ/60HZ | ||
Nominal Voltage | 12VDC | ||
Charging Current | 200A | ||
Housing | Aluminum Alloy | ||
Net /Gross Weight | Base on model | ||
Product dimension | Base on model | ||
Package dimension | Base on model | ||
CV-Lead acid-14.7V | 14.7V | ||
CV-LiFePO4-3.65V | 14.6(4S) | ||
CV-Lithium-4.2V | 12.6V/16.8V | ||
Charging Principle | Full automatic transition CC,CV and Float/Cut-off | ||
Charging Time | Cut-off point for Li battery is 5% of CC and it can be set between 3-10%. | ||
Transition for Lead acid charger is 20% of CC. | |||
High-Efficiency | ≥90% | ||
MTBF | ≥50000h | ||
Operating Temperature | -20℃~50℃ | ||
Store Temperature | (-40~80)℃ | ||
Related humility | 90%(40±2℃) | ||
Protection Function | Over-voltage | Over-temperature | Over-current |
Short circuit | / | ||
Indicators | Red means power on / charging, Green means full charged | ||
AC Plug | Accept any plug base on your request |
