PART 1. INTRODUCTION
DC/DC converter is a voltage converter which can effectively output fixed voltage after converting input voltage. DC/DC converters are divided into three categories: Boost type, boost & buck type, and buck type.
Three kinds of control can be adopted according to the demand. PWM control type has high efficiency and good output voltage ripple and noise. PFM control type has the advantage of low power consumption even if it is used for a long time, especially under small load.
PFM control is implemented when PWM/PFM converts to small load, and it is automatically converted to PWM control when heavy load occurs. At present, DC-DC converters are widely used in mobile phones, MP3, digital cameras, portable media players and other products. It belongs to chopper circuit in the classification of circuit types.
PART2. FEATURES
1 | Design meeting RoHS / CE |
2 | High efficiency: 93% |
3 | Isolated between input and output |
4 | Internal capacitor: NCC & NICHICON (high reliability) |
5 | 100% full load burn-in test |
6 | Over load, Over temperature and Over voltage protections |
7 | Waterproof level IP65 |
8 | 12 months warranty |
PART 3: TECHNICAL PARAMETER
Brand | IDEALPLUSING |
Type | Isolated |
Model | IPS-DTDYI48S1210 |
DC voltage INPUT | |
Voltage rate | 48VDC |
Voltage range | 30~60VDC |
DC voltage & Current output | |
Voltage rate | 12VDC |
Current | 10AMPS |
Rate Power | 120Watts |
Size | 74*74*32(MM) |
NW | 300G |
Others | |
Customize | Allow |
Material of shell | Aluminum |
Working temp | -20~80℃ |
Efficiency | 93% |
Waterproof Level | IP65 |
